Information
The YD2070-3 is a 60cm DTF printer built around two Epson i3200-A1 printheads, rated at 14 m²/h in 4-pass and 8 m²/h in 6-pass. It pairs with the DF-700W powder shaker at 4,300W.
It is the entry point into the 60cm class: the same working width as the four-head models, at a lower power and power-draw footprint — 1,400W for the printer.
Main Parameters
| Parameter | Specification |
|---|---|
| Printer model | YD2070-3 |
| Printhead | 2 × Epson i3200-A1 |
| Print speed | 4-pass: 14 m²/h ／ 6-pass: 8 m²/h |
| Control board | Hoson |
| Working size | Less than 60 cm |
| Ink type | Pigment ink, CMYK + White |
| RIP software | RIIN |
| Printer power | 1,400 W |
| Supply voltage | 220 V, 50/60 Hz (standard) |
| Printer packing size | 198 × 76 × 71 cm |
| Printer weight | 197 kg |
| Powder shaker model | DF-700W |
| Shaker power | 4,300 W |
| Shaker packing size | 126 × 115 × 128 cm |
| Shaker weight | 239 kg |
Selling Points
Large-format capability at an economic price point; includes an automated powder shaker (DF-700) for a continuous workflow.
Applications
- Shops moving from 30cm to 60cm — full-panel printing without tiling, at an entry-level price point.
- Mixed-output print rooms — a second 60cm line alongside higher-throughput machines for smaller jobs.
- Distributors’ demo and stock machines — a lower-cost 60cm unit that is easier to place with first-time buyers.
Compare with other models in the same series: YD2070 2 Head DTF Printer with DF-700 Powder Shaker, YD8076-3A 60cm DTF Printer, YD8074-3A 60cm DTF Printer.
FAQ
| # | Question | Answer |
|---|---|---|
| 1 | What power supply is required? | Printer 1,400 W plus shaker 4,300 W at 220 V / 50–60 Hz. Plan two circuits. |
| 2 | How does it differ from the YD2070-X5? | The YD2070-3 uses two Epson i3200-A1 heads at 14 m²/h (4-pass). The YD2070-X5 uses two Epson F1080-A1 heads at 5 m²/h (4-pass). |
